ZOUPW 220 Watt Solar Panel Kit for 12V/24V Battery, 2Pcs 110W 25.6% High-Efficiency Monocrystalline PV Module Power Charger with 30A LCD PWM Charge Controller for Off-Grid RV Marine Boat Rooftop Farm

Product description

1 Key Features

2 30A PWM Controller

3 Complete Solar Kit

1 25.6% Efficiency N-Type

2 Faster & Safer Controller

3 More Durable Structure

4 Longer Power Retention

5 Low Operating Heat

1 1.1kWh Daily Output

2 Quick 4-Step Setup

3 12V/24V Wiring Guide

1 Power Your Life

2 Cabin/Shed Energy

3 Off-Grid RV

4 Reliable Marine Solar

Will this solar kit work with my battery, and do I need to manually set the voltage?

Yes. The 30A controller auto-detects 12V/24V systems and supports LiFePO4, Lithium, GEL, Flooded, and AGM batteries. No manual setup is needed. Wire the panels in parallel for 12V systems, or in series for 24V systems.

Can I permanently mount these panels on my RV roof, and what about heavy rain?

Yes. The panels feature an IP68 waterproof rating and reinforced aluminum frame, ideal for permanent outdoor mounting in any weather. However, the 30A controller is not waterproof and must be installed indoors or in a dry compartment.

How much power can I realistically expect from this 220W (2x110W) setup in a day?

Under optimal sunlight (~5 peak sun hours), this kit generates roughly 1.1kWh daily—enough to run a 12V fridge for 24 hours. Note: Actual output varies based on real-world conditions like solar irradiance, weather, temperature, and humidity.

Can these solar panels operate reliably in extreme weather conditions?

Yes. Our N-Type cells are highly adaptable with a wide operating temperature range from -40°F to 185°F. Whether in freezing cold or extreme heat, they maintain a high conversion efficiency, ensuring stable and reliable power in any environment.

Tech Specs

STC Maximum Power (Single) 110 W STC Maximum Voltage (Single) 18.14 V STC Maximum Current (Single) 6.07 A Open-Circuit Voltage (Single) 21.14 V Short-Circuit Current (Single) 6.39 A Cell Type N-Type 16BB Monocrystalline Silicon Glass 0.13 in Tempered Glass Dimension 38.2 × 22.7 × 1.2 in Weight(Single) 13.45 lbs Operating Temperature -40 °F ~ 185 °F

【Versatile Off-Grid Solar Panels Kit】Generates up to 1.1kWh daily energy output with 5 hours of full sunlight. All-inclusive kit includes 2x110W N-Type panels, 30A PWM controller, Y connectors, Z brackets, PV and battery cables. Compact design fits Class B camper vans, RV, marine, boats, rooftops, farms, trailers, caravans, greenhouses, cabins, sheds and more off grid Applications.
【N-Type 16BB Performance】Premium N-Type cells with 16 busbar structure achieve 25.6% high efficiency, eliminating light-induced degradation. Delivers stable output even in low-light/cloudy conditions, with sturdy construction resisting road vibrations, perfectly stable for use on RVs, trailers and other mobile off-grid scenarios.
【Smart Controller & Anti-Shade Design】30A PWM controller auto-senses 12V/24V systems, compatible with lithium, gel, sealed and flooded batteries. LCD monitor, dual USB ports, 3-stage charging, and built-in safeguards (reverse polarity, overcharge, etc.) plus anti-shade bypass diodes ensure stable power.
【Durable & Expandable Design】IP68 waterproof with corrosion-resistant aluminum frame withstands strong wind and heavy snow. N-type cells feature low temperature coefficient maintains high output in extreme heat. Flexible for 12V/24V systems, PWM supports up to 400W input, easy series or parallel expansion with included connectors.
【Reliable Warranty & Support】We back our products with a 10-year warranty for solar panels and a 2-year warranty for the controller. 7*24 customer service and technical support are available to resolve your installation and product concerns efficiently.
